Technical Data

Electric pruner ...........................FHE 550 B2
Rated input voltage .............230V~, 50 Hz
Input power .................................. 550 W
Max. spindle rotation speed ...... 6100 min
Max. allowable rotation speed .. 8000 min
Safety class ........................................
Protection category ...........................IP20
Chain speed ............................. 10.8 m/s
Weight
without guide rail and
chain ............................. approx. 3.9 kg
with guide rail and chain .. approx. 4.4 kg
Oiltank .........................................70 cm
Chain bar ........ 10" Oregon Double Guard
Chain .......................... Oregon 91 P040X
Chain pitch. .............................3/8" (9.5 mm)
Number of chain drive links ....................... 40
Chain width ................................. 1.3 mm
Teeth of the sprocket chain wheel ............. 6
Sawing length (max.) ................... 260 mm
Acoustic pressure level
(L ) ...................88 dB(A);K
pA
Sound power level (L
guaranteed ........................... 104 dB(A)
measured ... 102.2 dB(A); K
Vibration (an) ........ 2.73 m/s
Noise and vibration values were deter-
mined according to the standards and
stipulations mentioned in the declaration of
conformity.
Technical and optical changes can be
carried out in the course of further devel-
opment without notice. All dimensions, ref-
erences and information of this instruction
manual are therefore without guarantee.
Legal claims, which are made on the basis
of the instruction manual, cannot thus be
considered as valid.
6
100SDEA041 (518693)
=3.0 dB(A)
pA
)
WA
=2.0 dB(A)
wA
; K=1.5 m/s
2
The stated vibration emission value was
measured in accordance with a standard
testing procedure and may be used to com-
pare one power tool to another. The stated
vibration emission value may also be used
for a preliminary exposure assessment.
-1
-1
Warning: The vibration emission
II
value may differ during actual use of
the power tool from the stated value
depending on the manner in which
the power tool is used.
Safety precautions aimed at protecting the
user should be based on estimated exposure
3
under actual usage conditions (all parts of
the operating cycle are to be considered, in-
cluding, for example, times during which the
power tool is turned off and times when the
tool is turned on but is running idle).

Notes on safety

This section deals with the basic safety
regulations while working with the electric
pruner.
An electric pruner is a dangerous
device, which can cause serious
2
or even fatal injuries with incorrect
or careless use. Thus, for your own
safety and the safety of others, you
should always take note of the in-
structions on safety and, in case of
difficulties, consult a specialist for
advice.
