KIT VALVOLE 1" 24V
1" 24V VALVE KIT
VENTILSET 1" 24V
24 В — КОМПЛЕКТ КЛАПАНА 1"
KIT VÁLVULAS 1" 24V
KIT KLEPPEN 1" 24V
Portata acqua (l/h) / Water fl ow (l/h)
Расход воды (л/ч) / Wassermenge (l/h)
Caudal de agua (l/h) / Waterhoeveelheid (l/h)
51
KIT VALVOLE 24V
Valvole 1" con attuatori fl ottanti
24 Volt - 3 punti
(utilizzabili solo con Quadro
QCV-MB).
B
ATTERIA PRINCIPALE
Grand.
Size
Типоразмер
Größe
Tamaño
H L
Grootte
1 54 245
2
54 245
3 54 295
4 58 291
5
58 367
6
59 416
7 59 516
B
ATTERIA AUSILIARIA
Grand.
Size
Типоразмер
Größe
Tamaño
M N
Grootte
1
50 249
2 50 249
3 50 299
4
54 295
5
54 370
6 55 421
7
55 521
24V VALVE KIT
1" valve
with 3 points - 24 Volt actuator
(available with QCV-MB control
only).
M
AIN BATTERY
Attacchi
Connections
Cod.
Соединения
Code
Anschlüsse
Conexiones
Art. Nr.
Koppelingen
Cód.
Ø Kvs
Code
1" 6,3 9034250
1" 6,3 9034251
1" 6,3 9034251
1" 10 9034252
1" 10 9034252
1" 10 9034270
1" 10 9034272
A
UXILIARY BATTERY
Attacchi
Connections
Cod.
Соединения
Code
Anschlüsse
Conexiones
Art. Nr.
Koppelingen
Cód.
Ø Kvs
Code
1" 6,3 9034253
1" 6,3 9034253
1" 6,3 9034253
1" 10 9034254
1" 10 9034254
1" 10 9034271
1" 10 9034273
