Internal
Connectors
LED Features
I/O Controller
Hardware
Monitor
Form Factor
BIOS Features
Continued from previous page
∙ 1x 24-pin ATX main power connector
∙ 1x 4-pin ATX 12V power connector
∙ 4x SATA 6Gb/s connectors
∙ 1x M.2 slot (M-Key)
∙ 1x USB 3.2 Gen 1 5Gbps connector (supports additional 2
USB 3.2 Gen 1 5Gbps ports)
∙ 2x USB 2.0 connectors (support additional 4 USB 2.0 ports)
∙ 1x 4-pin CPU fan connector
∙ 1x 4-pin system fan connector
∙ 1x Front panel audio connector
∙ 2x System panel connectors
∙ 1x Chassis Intrusion connector
∙ 1x Serial port connector
1x Parallel port connector
∙
∙ 1x TPM module connector
∙ 1x Clear CMOS jumper
∙ 4x EZ Debug LED
NUVOTON NCT6687-R Controller Chip
∙ CPU/ System/ Chipset/ MOS/ PCI-E temperature detection
∙ CPU/ System fan speed detection
∙ CPU/ System fan speed control
∙ Micro-ATX Form Factor
∙ 9.6 in. x 8.7 in. (24.4 cm x 22.0 cm)
∙ 1x 256 Mb flash
∙ UEFI AMI BIOS
∙ ACPI 6.0, SMBIOS 2.8
∙ Multi-language
Continued on next page
5
Specifications
