JFP1, JFP2: 前置面板接口
这些接口连接前置面板上的开关和 LED 灯。
Power LED Power Switch
2
1
HDD LED Reset Switch
JFP2
1
1
3
10
5
9
Reserved
7
9
Buzzer
1
Speaker 3
HDD LED +
HDD LED -
Reset Switch
Reset Switch
Reserved
HDD LED
POWER LED
Speaker - 2
Buzzer - 4
2 Power LED +
4 Power LED -
6 Power Switch
8 Power Switch
10 No Pin
HDD LED -
HDD LED +
POWER LED -
POWER LED +
Buzzer +
Speaker +
组件概述
11
