Storage
RAID
USB
Audio
LAN
Back Panel
Connectors
4
Specifications
Continued from previous page
AMD® A520 Chipset
∙ 4x SATA 6Gb/s ports
∙ 1x M.2 slot (From AMD processor, Key M)
▪ Supports PCIe 3.0 x4
▪ Supports SATA 6Gb/s
▪ Supports 2242/ 2260/ 2280 storage devices
∙ Supports RAID 0, RAID 1 and RAID 10 for SATA storage
devices
AMD® A520 Chipset
▪ 2x USB 3.2 Gen 1 5Gbps ports are available through the
internal USB 3.2 Gen 1 5Gbps connector
▪ 6x USB 2.0 ports (2 Type-A ports on the back panel, 4
ports through the internal USB 2.0 connectors)
AMD® Processor
▪ 4x USB 3.2 Gen 1 5Gbps Type-A ports on the back panel
Realtek® ALC892 Codec
▪ 7.1-Channel High Definition Audio
∙ 1x Realtek® RTL8111EPV 1Gbps LAN controller
∙ 1x VGA port
1x DVI-D port
∙
∙ 1x Serial port
∙ 1x HDMI port
∙ 1x PS/2 mouse port
∙ 1x PS/2 keyboard port
∙ 4x USB 3.2 Gen 1 5Gbps Type-A ports
∙ 1x LAN (RJ45) port
∙ 2x USB 2.0 Type-A ports
∙ 3x audio jacks
Continued on next page
