INFORMATION
Pull the Spectra Sock over the prosthetic foot to prevent noises in the
footshell.
Inserting the foot into the footshell
> Recommended tools: 2C100 changing device
1) Slide the prosthetic foot into the footshell.
2) Press the heel of the prosthetic foot into the footshell until it engages.
Removing the footshell
> Recommended tools: 2C100 changing device
1) Push the lock of the footshell to the rear and pull up the heel of the
prosthetic foot.
2) Remove the prosthetic foot from the footshell.
4.2 Alignment
4.2.1 Bench alignment (foot with footshell)
Foot size (cm)
21 - 22
23 - 25
26 - 28
29 - 30
4.2.2 Static alignment optimisation
If necessary, the alignment recommendations (TF modular leg prostheses:
646F219*, TT modular leg prostheses: 646F336*) may be requested from
Ottobock.
Use the L.A.S.A.R. Posture for static alignment optimisation of the prosthe-
sis, if available.
4.2.3 Dynamic alignment optimisation
Align the prosthesis in the coronal (ML) and sagittal (AP) plane by making
angular and /or slide changes to ensure the correct heel contact, a smooth
rollover and optimal forefoot transfer of weight onto the contralateral side.
16 | Ottobock
Mid-foot anterior to alignment line
30 mm
35 mm
40 mm
45 mm
Heel height
10 mm ± 5 mm
10 mm ± 5 mm
10 mm ± 5 mm
10 mm ± 5 mm
