ATX 12V Power Connector
(4-pin ATX12V1)
(see p.2 No. 1)
Chassis Intrusion Header
(2-pin CI1)
(see p.2, No. 23)
TPM Header
(17-pin TPMS1)
(see p.2, No. 6)
Downloaded from
www.Manualslib.com
Though this motherboard provides 24-pin ATX power connector,
it can still work if you adopt a traditional 20-pin ATX power supply.
To use the 20-pin ATX power supply, please plug your power
supply along with Pin 1 and Pin 13.
manuals search engine
20-Pin ATX Power Supply Installation
Please connect an ATX 12V
power supply to this connector.
This motherboard supports
CASE OPEN detection feature
1
GND
that detects if the chassis cover
Signal
has been removed. This feature
requires a chassis with chassis
intrusion detection design.
This connector supports
Trusted Platform Module (TPM)
system, which can securely
store keys, digital certiicates,
passwords, and data. A TPM
PCIRST#
FRAME
system also helps enhance
PCICLK
network security, protects
digital identities, and ensures
platform integrity.
FM2A88M Pro3+
24
12
13
1
