Montage; Installation; Anschlussbild Isohv525-M4 - Bender ISOMETER isoHV525 Kurzanleitung

Montage

70
L2/- L1/+
Signalleitung/Signal cables
(Drähte 1-11/Wires 1-11)
Frontalansicht/
Front view

Anschlussbild isoHV525-M4-4

Alle Maße in mm
3 (E) 4 (E)
L2/-
isoHV525
Signalleitung/Signal cables
(Drähte 1-11/Wires 1-11)
BU (L2/-) RD (L1/+)

Installation

96
Seitenansicht/
Side view
Wiring diagram isoHV525-M4-4
U
S
5 (KE) 1 (A1) 2 (A2)
L1/+
K1 K2
10 (14) 11 (24) 9 (11)
6 (T/R)
isoHV525_D00297_00_Q_DEEN / 08.2019
60
12.5
Unterseite/
Bottom view
All dimensions in mm
L1/+
L2/-
L3
PE
Test / Reset
7 (M-) 8 (M+)
V
0. . .10 V
ISOMETER® isoHV525
23.5
3
