Refer to figures 1 to 7.
1 - Pump
2 - Petrol/gasoline engines
3 - Frame
4 - Handle
5 - Handle securing screws (ENDURANCE)
6 - Handle securing washers (ENDURANCE)
7 - Handle securing nuts (ENDURANCE)
8 - Warning plate
9 - Accessory rack
11 - Water inlet hose-end fitting
12 - Water inlet hose clamp
13 - ID plate
14 - Base
15 - Water outlet fitting
16 - Water inlet fitting
17 - Pressure regulating knob
18 - Pressure indicator
19 - Spray gun
20 - Thermal valve
21 - Single barrel lance hose
23 - Water inlet filter (ENDURANCE)
24 - Single barrel nozzle holder head
25 - Detergent tank
26 - Detergent tank cap with dosing device
27 - Oil plug with vent for pump
29 - Nozzle cleaning needle
• Pressure unloader/regulation valve
Valve, suitably calibrated by the Manufacturer, for regulating work pressure by means of a knob (17)
and that allows the pumped fluid to return to pump suction thus preventing the onset of dangerous
pressures when closing the spray gun or when trying to set a pressure that is above the maximum
permitted values.
• Spray gun lever lock device.
Safety stop (32) for locking the spray gun (19) lever (33) in the closed position so it cannot be started
accidentally (Fig. 6, position S).
• thermostatic valve: designed to prevent the pump gaskets from overheating during prolonged
operation in bypass.
Make sure the following are inside the pack of the product you have purchased:
• high pressure cleaner;
• handle (not for FDX BLADE XL/PRO as it is integrated in the frame);
• high pressure delivery hose;
• spray gun;
• lance hose;

IDENTIFICATION OF COMPONENTS

SAFETY DEVICES

STANDARD FITTING
30 - High pressure hose
31 - Detergent suction hose
32 - Spray gun lever safety stop
33 - Spray gun lever
34 - High pressure hose quickfit coupling
36 - Detergent suction fitting
37 - Detergent suction hose clamp
38 - Pump oil level indicator
39 - Water inlet filter (BLADE XL)
40 - Detergent suction filter
41 - Brake (ENDURANCE)
42 - Battery (ENDURANCE)
43 - Ignition key (ENDURANCE)
44 - Gearbox oil level indicator (BLADE XL PRO)
45 - Water inlet filter (BLADE XL PRO)
46 - Oil plug with vent for gearbox (BLADE XL
PRO / ENDURANCE)
49 - Water inlet filter gasket (BLADE XL PRO)
50 - Water inlet filter cartridge (BLADE XL PRO)
51 - Water inlet filter cap (BLADE XL PRO)
52 - Casing screws (ENDURANCE)
56 - Casing (ENDURANCE)
61 - Water inlet filter cup (ENDURANCE)
62 - Water inlet filter ring nut (ENDURANCE)
63 - Water inlet filter cartridge (ENDURANCE)
