3 Ball valve mount
4 Drain pipe mount
5 Floor brackets
6 Pipe bracket for ball valve
7 Ball valve
8 Connecting pipe ball valve
9 Connecting tube
10 Pipe bracket for drain pipe
11 Drain pipes (3 pieces)
12 Pipe bracket for unit connection
13 Silicone seal
14 Sealing plugs for cooking chamber,
with attachment and chain
15 Hot surface stickers
16 Teflon tape
17 Drain pipe with handle
18 Lid for drain container
19 Drain container
20 Vat for drain container
Scope of delivery conversion kit for
mobile racks [ Photo
1 Drip rail
2 Additional drip vats
3 Drip tray
4 Fat collector vat
5 Supporting rails
4

Installation

4.1 Installing the integrated fat drain

Installing the floor brackets and ball valve
1. Attach the floor brackets and base
clamping plates to the top of the feet
using the cap nuts supplied
[ Photo 03].
10 / 72
02]
80.51.382_iCombi Pro-iCombi Classic_IFA SG_IM_V01_EU-west
2. Seal the threads of the two pipe pieces
for the ball valve with Teflon tape
[ Photo 04].
3. Install the pipe pieces, pipe bracket and
ball valve [ Photo
ferent assembly for the left and right
variant.
4. Install the assembled ball valve with
the clamping parts on the rectangular
pipe [ Photo
cap nuts yet. The assembly must re-
main moveable for the subsequent
steps.
>
The drain pipe points to the rear
and the pipe bracket to the bottom.
5. Attach the rectangular pipe with the
cap nuts to the clamping brackets of
the floor brackets [
6. Attach the pipe brackets to the rectan-
gular pipe with the cap nuts and the
clamping parts [
tighten the cap nuts yet. The assembly
must remain moveable for the sub-
sequent steps.
>
The pipe bracket with an arrow
pointing upwards is installed at the
rear end of the rectangular pipe.
>
The pipe bracket with an arrow
pointing down is installed in the
middle on the rectangular pipe.
Install drain pipes [
1. Install the pipe seal on the pipe socket
in the rear wall of the unit.
2. Insert the pipes together.
3. Connect the piping to the ball valve
and to the connector on the rear of the
unit.
4. Check the piping. There must be a
slight gradient towards the ball valve.
4 | Installation
05]. Note the dif-
06]. Do not tighten the
Photo 07].
Photo 08]. Do not
Photo 09]
