3.18 Camber adjustment function
Working principle:
1. Keep the wheels off the ground in the same angle status as that when they are on the ground measurement platform by using the
computer program.
2. Click camber adjustment button to enter the current interface, during which the camber adjustment function is enabled.
3. Make sure that the service brake and the parking brake are properly fixed; straighten and fix the steering wheel; lift the vehicle to a
certain height.
4. Press M key to enter the system, and adjust the data to the specified value (follow the on-screen prompts)
5. After that, click camber function button, lower the vehicle and shake the front axle to return the suspension to the original position, and
then press M key to disable the camber adjustment function.

Camber adjustment

Camber adjustment
AE5606S
Beginning of camber adjustment
Please lift the vehicle until the wheels are off the
ground, and then press M key after the vehicle is
stable.
End of camber adjustment
After the adjustment, please lower the wheels to
the ground, and then press M key to disable the
function after the vehicle is stable.
