Check the presence of all the following compo-
nents:
N°1 frame (Ref. A)
N°1 resistance unit (Ref. B)
N°1 unit support upper base (Ref. C)
N°1 unit support lower base (Ref. D)
N°1 screw M6 x 45 mm (Ref. E)
N°1 washer Ø 6 mm (Ref. F)
N°1 nut M6 (Ref. G)
N°1 bag of unit accessories:
N°1 hex wrench
N°2 screws M6 (Ref. H)
N°2 washers Ø 6 mm (Ref. I)
N°1 quick release (Ref. L)
N°8 levelling (equalizing) feet (Ref. M)
N°2 front levelling wedges (Ref. N)
N°2 screws Ø 3,5x14 (Ref. O)
N°2 M4 washers (Ref. P)
Resistance unit depicted here may vary
from production models
ce.
to the upper base unit support (C) to the frame
tubing (fig. 2) within the limits indicated on the
sticker (fig. 3) and tighten with screw (E) + washer
(F) + nut (G) (fig. 4).
with the screws (H) + the washers (I) (fig. 5).
the various holes according to the diameter of the
bicycle wheel:
for 26" wheels, pair of front holes (fig. 8).
wheel is properly fixed.
10).
of the rear quick release in the left bushing (fig.
11). For safer clamping of the bicycle on the
stand, make sure the lever of the quick release is
horizontal (fig. 12).
tacts the quick release within the predefined
working range of 55° to 65° (Fig. 13).
release before attaining the predefined range (fig.
14), screw in the right pin bushing (R) (fig. 15) so
predefined working range of 55° and 65°(fig. 13).
beyond the predefined range (fig. 16), unscrew
the left pin bushing (R) (fig. 17) so that the lever
the predefined working range of 55° to 65° (fig.
13).
-
middle of the roller (fig. 18), shift the resistance
unit (B) by loosening the unit fixing screws (H) and
secure them in the more correct position (fig. 19,
20 and 21).
move the entire base (C, D), loosening the base
(fig. 22) fixing screw and securing it in a more
correct position (fig. 21).
until the rear wheel touches the roller (fig. 23).
pushing the top tube of the frame and the saddle.
