11 Technical Data

11.1

General Data

Display:
Digit height:
Data retention:
Operation:
11.2

Measuring signal inputs

Sampling rate:
Input Thermocouple
Sensor
Fe-CuNi J
NiCr-Ni K
Cu-CuNi T
NiCr-CuNi E
NiCrSi-NiSi N
Pt10Rh-Pt S
Pt13Rh-Pt R
Pt30Rh-Pt6Rh B
Resolution J, K, T, E, N:
Resolution S, R, B:
Temperature drift:
Reference point:
(cold junction)
Reference point accuracy:
Input mV
Measuring range:
Resolution:
Measuring accuracy
@ 23°C:
Temperature drift:
Input resistance:
Input Pt100
Measuring range:
Resolution:
Measuring accuracy
@ 23°C:
Temperature drift:
Measuring current :
Connection:
Lead wire resistance:
Page 18
6-digit, 14 segment LED
14 mm
> 10 years, EEPROM
5 keys
10 readings/sec.
Range Accuracy
@ 23°C
-210.0 ... typ. 0.2°C
+1200.0°C max. 0.5°C
-200.0 ... typ. 0.6°C
+499.9°C max. 1.0°C
-500.0 ... typ. 0.3°C
+1372.0°C max. 0.5°C
-200.0 ... typ. 0.2°C
+400.0°C max. 0.5°C
-200.0 ... typ. 0.2°C
+1000.0°C max. 0.5°C
-200.0 ... typ. 0.3°C
+1300.0°C max. 0.7°C
-50 ... typ. 1.0°C
+1768°C max. 2.0°C
-50 ... typ. 1.0°C
+1768°C max. 2.0°C
+250 ... typ. 1.0°C
+1820°C max. 2.0°C
1 or 0.1°C/°F
1 °C/°F
< 100 ppm/K
internal or
external constant
±1°C
± 105 mV
± 15 Bit
typ. 0.02 % of range
max 0.05 % of range
< 100 ppm/K
> 2 M
-200 ... +850°C
1 or 0.1°C/°F
typ. 0.3°C
max. 0.6°C
< 100 ppm/K
200 A
2-, 3-, 4-wire
max. 25 per wire
Input 500
Measuring range:
Resolution:
Measuring accuracy @ 23°C: typ. 0.1
Temperature drift:
Measuring current:
Connection:
Lead wire resistance:
11.3

Control Inputs MPI 1 / MPI 2

Quantity: 2, optocouplers
Function: programmable
Switching levels: Low: < 2 V
High: > 4 V (max. 30 V)
Pulse length: > 100 ms
11.4

Alarm outputs

Relays: changeover contacts
Switching voltage: max. 250 V AC / 125 V DC
min. 5 V AC / 5 V DC
Switching current: max. 5 A AC / A DC
min. 10 mA DC
Switching capacity: max. 1250 VA / 150 W
Pull-in time: approx. 10 ms
Mechanical service life (switching cycles)
N° of switching cycles at 5 A / 250 V AC
N° of switching cycles at 5 A / 30 V DC
11.5

Supply voltage

AC supply: 90 ... 260 V AC / max. 9 VA
50 / 60 Hz
ext. fuse protection: T 0.1 A
DC supply: 10 ... 30 V DC / max. 3.5 W
with galvanic isolation and,
reverse polarity protection
ext. fuse protection: T 0.4 A
Mains hum 50 Hz or 60 Hz
suppression: programmable
11.6

Sensor Supply Voltage

AC supply: 24 V DC
11.7

Climatic Conditions

Operating temperature: -20°C ... +65°C
Storage temperature:
Relative humidity:
Altitude:
11.8

EMC

Noise immunity: EN61000-6-2
with shielded signal and
control cables
Noise emission: EN55011 Class B
0 ... 525
15 Bit
max. 0.2
< 100 ppm/K
200 A
2-, 3-, 4-wire
max. 25 per wire
1x10
5x10
5x10
15 %, 30 mA
-25°C ... +75°C
R.H. 93 % at +40°C,
non-condensing
up to 2000 m
www.kuebler.com
7
4
4
