Identify the Parts of the Prism Printer

Front View

Control Panel

There are four indicator lights and an operator button on the operator panel located on the front of the
printer.

Operator button

Press the operator button to open and close the printer tray. There is a yellow indicator light in the center of
this button.
2
Downloaded from www.Manualslib.com
Clamping Pins
Printer tray and
Centering Pin
Operator button
with
indicator light
Disc Not Present
indicator light
Active indicator light
Power indicator light
manuals search engine
Ribbon Guides
Supply Roller
Take-up Roller
