Rear View
Side view
Downloaded from www.Manualslib.com
USB port: Upstream (1 Port)
A USB-ready computer or
self-powered USB hub can be
connected here.
Main power switch
(I) Turns the monitor on.
(O) Turns the monitor off.
manuals search engine
Product description
Ventilation
openings
Security lock anchor
By connecting a security lock (purchased sepa-
rately) to the security lock anchor, the monitor is
fixed so that it cannot be transported.
The theft prevention hole works in conjunction with
Kensington Micro Saver Security Systems.
USB port: Downstream
(2 ports)
A USB device can be con-
nected here.
11
Note: Never block the
ventilation openings as this
may lead to overheating
inside the monitor and result
in malfunction
Power connector
The power cord is
connected here.
RGB signal cable
This is to be connected to
the computer's analog RGB
output terminal.
