3. In Show Data screen, scroll through each stored data record by pressing UP
buttons.
Example: 02 = Show Data List Counter: TQ = Peak torque value
01 = Show Data List Counter: TQ = Peak torque value: ANG = Peak angle value
4. Pressing ENTER
00
100.0
FT-LB
M
Target Screen
Note: A maximum of 50 data records can be stored in memory. Memory full icon will be displayed
when full. New data will replace oldest record until memory is cleared.
Deleting Stored Torque and Angle Data
1. From target torque or angle screen, press and hold ENTER
2. Highlight

CLEAR DATA

button to display CLEAR ALL DATA screen.
3. In CLEAR ALL DATA screen, highlight
selection to exit without deleting data.

4. Press ENTER button after making selection.

00
100.0
FT-LB
M
Target Screen
Viewing and Clearing Wrench Cycle Counter
Each time torque or angle target is reached, wrench cycle counter is incremented. Maximum cycle
count is 999999.
1. From target torque or angle screen, press and hold ENTER
2. Highlight CYCLE COUNT

3. Press ENTER button to display CYCLES screen.

4. To exit CYCLE COUNT screen without clearing count, press ENTER
selection is highlighted.
5. To reset wrench cycle count to 0, highlight
6. EXIT menu selection is automatically highlighted after count is cleared. Press ENTER
return to main menu.

button while on Show Data screen returns to main menu.

