00
100.0
FT-LB
M
Target Screen
00
OFFSET IN USE
100.0
FT-LB
M
Note: Head length entered is offset length measured from center of drive to center of fastener.
Use of Negative Offsets
Note: Enter a negative value for offset when used in reverse direction.
When length of an offset is negative, maximum fastener target is limited by following formulas:
240 in-lb wrench:
Maximum Target Torque =
offset * 24 + 240
Offset Max Target
-1" 216 in-lb
-2" 192 in-lb
-3" 168 in-lb
-4" 144 in-lb
Note: When using a negative offset, entering a target torque greater than maximum values above
may cause an overtorque error before reaching fastener target torque and possibly damage
wrench.
Viewing Stored Torque and Angle Data
Torque data is stored in memory after each torque cycle if applied torque has reached target value.
Torque and angle data is stored in memory after each angle cycle if applied angle has reached target
value. Memory Indicator is displayed when data is stored in non-volatile memory.
1. To view stored torque and angle data, from target torque or angle screen, press and hold ENTER

button for 3 seconds.

2. Highlight SHOW DATA

ENTER button to display Show Data screen.

ENTER
EXIT
button
SET HEAD LENGTH
held
SHOW DATA
CLEAR DATA
M
ENTER button (after length change)
Maximum Target Torque =
offset * 8 + 100
Offset
-1"
-2"
-3"
-4"
menu selection by pressing UP
ENTER
SET HEAD LENGTH
button
0.000
M
M
UP/DOWN buttons
100 ft-lb wrench:
Max Target
92 ft-lb
84 ft-lb
76 ft-lb
68 ft-lb
/DOWN


6
UNITS
button
SET HEAD LENGTH
0.0
IN
M
M
UP/DOWN buttons
250 ft-lb wrench:
Maximum Target Torque =
offset * 12 + 250
Offset Max Target
-1" 238 ft-lb
-2" 226 ft-lb
-3" 214 ft-lb
-4" 202 ft-lb
buttons then press


MM
