Contents
1
Publishing notes .................................................8
2
Explanation of symbols ......................................8
3
Required tool and auxiliaries .............................8
4
Description ..........................................................8
5
Preparing for assembly ......................................8
6
Mount the press seal ..........................................8
7
Disassemble the press seal ................................9
8
Attaching the FHRK seal .....................................9
1
Publishing notes
Copyright © 2020 by
Hauff-Technik GmbH & Co. KG
Dept.: Technical Editing
Robert-Bosch-Straße 9
89568 Hermaringen, GERMANY
Tel.
+49 7322 1333-0
Fax
+49 7322 1333-999
E-Mail
offi ce@hauff-technik.de
Internet
www.hauff-technik.de
Reproduction of these assembly instruction – even in
extracts – in the form of reprint, photocopy, on electro-
nic data media or using any other method requires our
written consent.
All rights reserved.
Subject to technical alterations at any time and without
prior announcement.
These installation instructions form part of the product.
Printed in the Federal Republic of Germany.
2
Explanation of symbols
1
Work stages
►
Effect/result of a work step
1
Reference numerals in drawings
3
Required tool and auxiliaries
To install the press seal correctly, you will need the fol-
lowing tools, auxiliaries and accessories in addition to the
usual tools:
Werkzeuge:
1 Torque spanner
1 Extension
1 Socket allen screw
Auxiliaries:
Lubricant GM (Article no.: 0804020000)
KRMTX cable cleaner (Hauff)
Vernier calliper
Cleaning cloth
8
4
Description: HSD100 EW 1x24-44+4x7-12 b40 (siehe
Legend for fi g.: 1
1
2
3
4
5
6
5
1
Legend for fi g.: 2
1
2
3
Legend for fi g.: 3
1
6
1
2
Art. Nr.: 5090031085
Rev.: 00/2020-01-22
Description
Abb.: 1).
Rear press plate U-profi le
Segment ring
Elastomer segment HSD100 RW
1x25/32/40+3x6-18 b40 (Grade: EPDM or NBR)
Blindplug
Front press plate U-profi el
Hexagon socket screw
Preparing for assembly
Clean the core drilling/liner and media line.
Level out any chips and/or voids which may be
present.
Check the diameter tolerance of the core drilling/
liner (D) and media line (d1/d2), as well as outer or
drilling dimension of the press seal (see fi g.: 2).
The wall sleeve must be dimensionally accurate,
smooth and inherently stable.
D
= 99 mm / D
= 102 mm
min
max
d1= 24 - 44 mm
d2= 7 - 12 mm
Adapter rings are available for core drill holes/
wall sleeves with inner diameter 104 mm and
110 mm. The adapter ring must be installed
before laying the cables (see fi g.: 3)! Please
refer to a separate installation instructions for
„Adapter Ring AR".
Adapter ring
Application range:
1 cable Ø 24-44 mm
4 cables Ø 7-12 mm
Mount the press seal
Remove the blindplug (see fi g.: 4).
Push unneeded segment rings (see table 1) (see
fi g.: 5) backwards with a screwdriver (see fi g .: 6).
