30 | ENG
Symptom
Display unit and/or
Brose Drive System
cannot be activated.
Display unit does not
provide trip data even
though the e-bike is
in motion.
Bicycle lighting
cannot be activated.
Display unit indicates
an error in the
multifunction panel.
Tab. 08: possible fault causes
Possible cause
Battery not correctly clicked
into the holder.
Battery not charged up.
Battery contacts and/or
holder soiled.
Display unit not correctly
connected.
Display unit contacts and/or
holder soiled.
Plug connections on the
drive unit not correctly
inserted.
Spoke magnet not correctly
mounted (distance to the
speed sensor).
Lighting cable incorrectly
connected.
There is an active error in
the system.
Troubleshooting | Remote
Solution
If possible, remove the battery and
reinsert it. Pay attention that it is in
the proper position.
Charge up fully using the supplied
battery charger.
Make sure all contacts are clean. If
necessary, clean with a soft, dry cloth.
Check the plug connection of the
display unit. Pay attention that is it
properly connected.
Make sure all contacts are clean. If
necessary, clean with a soft, dry cloth.
Check cabling and connections and
connect them correctly if necessary.
Check the mounting of the spoke
magnet, in particular its distance to
the speed sensor on the chainstay.
This must be between 5 and 17 mm
(see Fig B). Correct the distance if
necessary.
Check cabling and connections and
connect them correctly if necessary.
Please note table 07.
