3.3. Technical Data

Control Unit
Brose material no.
L × W × H
Weight, approx.
Handlebar (d)
Electrical data
Operating and storage
temperature
Operating frequence
IP X7 (HMI) water-tight
CAN Interface ISO 11898 highspeed CAN
Certificates
FCC ID
IC
BLUETOOTH low energy® 5.0 (optional ANT+)
Frequenz
Sendeleistung
Tab. 02: technical Data

4. Assembly

The control unit can be mounted on both the
left and the right side of the handlebar.
Brose recommends positioning on the left side
of the handlebar.
Check all fixing screws regularly. Shocks, heat
and cold can cause the screws to become
loose. Tighten all screws to the required
torque.
E 41227
46 × 43 × 21 mm
35 g
22,2 mm
12V / max 3W
-10°C bis 60°C
2400-2480 MHz
CE, ROHS, Reach,
Bluetooth (EU,
Switzerland, USA,
Canada, Japan)
O4GRE
7666A-RE
2400–2480 MHz
< 10 mW

3.4. Declaration of Conformity

Brose Antriebstechnik GmbH & Co. KG hereby
declares that the «Display Remote» wireless
system complies with Directive 2014/53/
EU. The full text of the EU Declaration of
Conformity is available at the following Internet
address(Service/Servicetool):
www.brose-ebike.com
› Carefully remove the grip and open the
brake, gears and all other components
mounted on the selected handlebar side.
› Carefully loosen the hexagon socket screw
with a size 2 wrench (Fig. C-g) on the
control unit.
» NOTE: The screw cannot be removed
from the control unit.
› Now slide the control unit from the side
onto the handlebar.
