22 | ENG

3. Product Description

3.1. Explanation of Illustrations
(b)
(c)
(d)
(e)
Fig. 1: Key Assignment
Control Unit E 41227 (Fig. B/Fig. 1)
(a) «On/Off» key
(b) «Menu» key / select key
(c) «Light» key
(d) «Increase» assistance level /
scroll menu up
(e) «Decrease» assistance level /
scroll menu down
(f) «Walk Assit» key / menu back one level
(g) Control unit grub screw
(h) Plugs
Tab. 01: Tastenbeschreibung
The numbering of the described components
also refers to the illustrations on the graphics
pages at the beginning of the manual. All
(a)
illustrations are schematic and may differ in
details from the actual features of your e-bike.
3.2. Brose Display Remote
The Brose displays ensure an optimal
interaction
These new Brose control units are precisely
coordinated to the Brose Drive product family.
This allows the rider to enjoy a holistic e-bike
experience.
With three compact, ergonomically designed
displays, Brose grants very different cyclist
wishes.
(f)
Consistent purists get their money's worth
with the slimline Brose Display Remote. All
important functions such as the assistance
level, light and Walk Assist are stored in six
easy-to-feel keys. An LED light strip in the slim
but robust housing delivers information about
the battery charge, level of assistance or Walk
Assist.
From stylish city bike to sporty E-mountain
bike, the smallest Brose display hugs the
handlebar and provides as much information
as needed in as little space as possible.
Anyone who wants more values displayed at
a glance also uses the Brose Display Central.
Product Description | Remote
between cyclist and drive.
