24 | ENG
› Position the control unit close to the grip,
so that all keys can be easily pressed with
the thumb.
› Now tighten the hexagon socket screw
slightly with a size 2 wrench. Do not
tighten the screws yet. Check the position
of the control unit.
» Can all keys be reached with the thumb?
» Is the display clearly visible?
› Tighten the hexagon socket screw with the
wrench (Fig. C-g).
» Torque 0.5 Nm

5. Operation and Control

5.1. Before First Use

Commissioning of the display and control unit
requires no further steps after installation. The
display/control unit is ready for use as soon as
it has been correctly connected and the battery
is sufficiently charged.
A full function is only possible if the speed
sensor and all cables have been connected
correctly and the battery is charged (min. one
white LED visible).
The display unit does not have its own battery
and therefore cannot be used or operated
outside the e-bike.
If the e-bike is switched on, the display unit
remains switched on while riding; even if the
motor assistance is deactivated.
5.2. Basic Control Elements
With the control unit keys, you can ergonomically
control the functions of the e-bike system. The
hand can remain on the handlebar grip while
Operation and Control | Remote
› Connect the control unit cable to the motor
cable connectors (Fig. C-h). This may vary
depending on the features of your e-bike.
Please make sure that the operation of safety-
relevant parts (e.g. brake grips) is always
ensured.
Make sure that the connection cable is not
crushed or bent.
the thumb operates the control unit keys. The
information on the display tells you about the
selected assistance level and gives you more
information about your Brose Drive System.
Switch the e-bike on or off with the «On/Off» key
(Fig. 1-a).
Use the «Increase» (Figure 1-d) and
«Decrease» (Figure 1-e) keys to increase or
decrease the assist level.
With the «Light» button (Fig. 1-b) you can
switch the bike lighting on or have it controlled
by a light sensor.
The push assistance function can be activated
using the «push assistance» button (Fig. 1-f).
All the interface illustrations and text on the
following pages correspond to the release
status of the software.
The software can be updated several times
during a year. An update can change the
display slightly, Please contact your dealer.
