SEH UT 16 Schnellinstallationsanleitung Seite 7

Print Server Parameters
All print server data required for installation can be found on the status page.
The status page can be printed out simply by pressing the status button on the
print server.
Hardware Address
A print server can be addressed by its world-wide unique hardware address. This
address is glued to the network board or to the housing of the box or pocket
print server. If the print server has already been installed, the hardware address
may be found on the status page, among other places.
Print Server Name
The print server has a default name which is set at the factory and cannot be
changed. The default name consists of two letters 'IC' and the last six digits of the
hardware address.
Example:
Hardware address: 00:c0:eb:00:01:ff
Print server name: IC0001FF
In Novell and Apple networks, the Novell or Apple name is used. Upon delivery of
the print server, the default name corresponds to the Novell or Apple name. By
means of the print server homepage, the PRINTSERVER-NetTool, or parameter
transfer via FTP, it is possible to change the Novell or Apple name.
IP Address
The IP address is a clear address for every node in your network, i.e., an IP address
may appear only once in your local network. The system administrator usually
assigns the IP address. It must be stored in the print server so that the print server
can be addressed within the network. For this purpose, various possibilities are
available. For more information on this topic, please read the detailed description
in the User Manual.
Host Name
The host name is an alias for an IP address. It is usually recommended that host
names should be used in your network. The host name used to address the print
sever in your local network may be chosen freely. It is, however, recommended to
select a name associated with the respective board, such as IC0001FF, or with the
printer.
Quick Installation Guide (en) 7
