Mounting the Print Server
The printer models CD 1216 and CD 2216 can be connected to the network via
the USB port 1 of the UT 16 print server.
The print server has been designed exclusively for the mentioned
printer models. Do not connect the print server to other printer models!
1. Turn the printer off.
2. Disconnect the printer's power cord.
3. Connect the print server (USB port 1) and the printer to the
4. Connect the network cable (RJ-45) to the print server.
5. Connect the print server to the power cord (DC 5V) which is
6. Connect the printer's power cord to the printer.
7. Turn the printer on.
8. Press the status button of the print server in order to print out
6
Proceed as follows:
data cable (USB 2.0) which is enclosed in the package.
enclosed in the package.
a status page.
