Rückansicht - SPL Phonitor x Bedienungsanleitung

Rückansicht
Netzspannung
Netzschalter
~ 115V AC / ~230V AC, 50 Hz / 60 Hz, P max. 45 W
Phonitor x
Made in Germany
IR PGM-Volume
6
14
13
Voltage Selection:
1. Remove Fuse Holder
2. Exchange Fuses
3. Flip Over 4. Reinstall
Fuses: 230V AC: T 500 mA L 250 V
115V AC: T 1 A L 250 V
A L
IR
B R
PGM
Serial
Refer to
Number
Manual
Connect to SPL
Power Amp(s) for
remote power on/off
AMP CTL SPEAKER OUTPUTS
17 19
AMP CTL 18
15 Analoge Audio-Eingänge
C A U T I O N DIP SWITCHES
RISK OF ELECTRIC SHOCK ON BOTTOM SIDE:
D O N O T O P E N
1 ON: HP Out +22dB
2 ON: HP Out +12dB
AVIS: RISQUE DE CHOC ÉLECTRIQUE • NE PAS OUVRIR 3 ON: VU 0 = +10dB
L
R
R L R
ANALOG SOURCES
Audio-Ausgänge
16 Digitale Audio-Eingänge
optional
W I R I N G
XLRs: balanced, Pin 2 = Hot (+)
4 ON: XLR Direct Out
For unbalanced operation
5 ON: RCA Direct Out
6 ON: AMP CTL power off bridge Pin 3 to GND.
when listening to RCAs: Unbalanced, Tip = Hot (+)
COAX
L
OPTICAL USB
DIGITAL SOURCES
I F R B
Rückansicht
