Rückansicht
Netzspannung
Netzschalter
~ 115V AC / ~230V AC, 50 Hz / 60 Hz, P max. 45 W
IR PGM-Volume
6
15
14
Voltage Selection:
1. Remove Fuse Holder
2. Exchange Fuses
3. Flip Over 4. Reinstall
Fuses:
230V AC: T 500 mA L 250 V
115V AC: T 1 A L 250 V
Phonitor xe
IR
PGM
Serial
Number
Balanced
Standard
Refer to
Manual
HEADPHONES OUTPUTS
Made in Germany
20
18
19
Symmetrischer Kopfhörer
16
Analoge Audio-Eingänge
C A U T I O N
DIP SWITCHES
ON BOTTOM SIDE:
RISK OF ELECTRIC SHOCK
D O N O T O P E N
1 ON: HP Out +22dB
2 ON: RCA -10dBV to 0dBu
AVIS: RISQUE DE CHOC ÉLECTRIQUE • NE PAS OUVRIR
L
R
R
L
ANALOG SOURCES
Standard-Kopfhörer
I
17
Digitale Audio-Eingänge
optional
W I R I N G
XLRs: balanced, Pin 2 = Hot (+)
For unbalanced operation
bridge Pin 3 to GND.
RCAs: Unbalanced, Tip = Hot (+)
COAX
AES
OPTICAL
USB
DIGITAL SOURCES
F R B
