Rückansicht

Netzspannung

Netzschalter
50 Hz / 60 Hz, P max. 35 W
IR Remote Learn
6
16
15
Voltage Selection:
1. Remove Fuse Holder
2. Flip Over 3. Reinstall
Fuses: 115V AC: T 1 A L 250 V
230V AC: T 500 mA L 250 V
~ 115V AC / ~230V AC
Learning Volume Up/Down:
1. Press LEARN button below
2. Point your remote at VUs
and press a button for
VOLUME DOWN (LEDs flash 1x)
Phonitor 2
3. Repeat until LEDs flash 3x
LEARN
PGM
Serial
4. Press a button for This output can also drive balanced headphones
Number
VOLUME UP (LEDs flash 1x) (Gender changer may be required).
5. Repeat until LEDs flash 3x
IR REMOTE
Made in Germany
18
17
C AU T I O N D IP S W IT C H
RISK OF ELECTRIC SHOCK
D O N O T O P E N
1 ON: Output +12dB
2 ON: Output + 6dB
AVIS: RISQUE DE CHOC ÉLECTRIQUE • NE PAS OUVRIR
L
R
3 2
R L R
OUTPUT
19 Audio-Ausgänge
Analoge Audio-Eingänge
W IR IN G
ON BOTTOM SIDE: XLRs: balanced, Pin 2 = Hot (+)
For unbalanced operation
3 ON: RCA -10dBV to +4dBu
bridge Pin 3 to GND.
4 ON: Sources 1:1 to Output
RCAs: Unbalanced, Tip = Hot (+)
1
L R L
SOURCES
I F R B
Rückansicht
