Rückansicht - SPL Phonitor e Bedienungsanleitung

Rückansicht
Netzspannung
Netzschalter
6
11
10
~115 V AC/~230 V AC,
50 Hz/60 Hz, P max. 30 W
Fuses:
230 V: T 500 mA L 250V
115 V: T 1 A L 250V
Voltage Selection:
1. Remove Fuse Holder
2. Exchange Fuses
3. Flip Over
4. Reinstall
C A U T I O N AT T E N T I O N
RISK OF ELECTRIC SHOCK RISQUE DE CHOC ÉLECTRIQUE
Made in Germany
D O N O T O P E N N E P A S O U V R I R
IR PGM-Volume
12 Analoge Audio-Eingänge
Phonitor e L
IR
Serial
R
Number
PGM
R
Refer to
DIP SWITCHES 1 ON: Output +22dBu Manual
ANALOG SOURCES
2 ON: RCA -10dBV to 0dBu
ON BOTTOM SIDE:
14
13 Digitale Audio-Eingänge
optional
COAX
OPTICAL
L
Pin 2 +
DIGITAL SOURCES
I F R B
Rückansicht
