GEZE P03 Technische Daten Und Installationshinweise Seite 10

Regen- / windsteuerung mit wetterstation
Inhaltsverzeichnis

Werbung

Betrieb / Operation
(a)
(b)
1
17
13
L1 N PE
2
3x1.5 mm
230 V AC
50/60 Hz
12
2x1.5 mm
1
Primärsicherung M 100 mA / Primary fuse M 100 mA
2
Einstellung der Betriebsart mit Jumper /
Setting of operating mode with jumper
(a)
Relais getrennt / Separate relay operation
(b)
Relais gemeinsam / Common relay operation
3
Einstellung der Windgeschwindigkeit /
Setting of the wind speed
4
Kontroll­LED (blinkt, wenn Verbindung zur Wetter­
station OK ist) / Control LED (flashes if connection to
weather station is OK)
5
LED (Wind) / LED (wind)
6
LED (Regen) / LED (rain)
7
Windalarm / Wind alarm
8
Signal
10
2
15
16
14
14
2
2
2x1.5 mm
11
Wetterstation P03 / Weather station P03
3
LED
LED
5
6
1
2
2 x 2 x 0.8 mm
(max. 30 m)
1
2
3
9
Wetterstation / Weather station
10
Anzeigemodul / Display module
11
Wetterstation mit Regenfühler, Windfühler und Außen­
temperaturfühler / Weather station with rain sensor,
wind sensor and outside temperature sensor
12
potentailfreie Schließer max. 3 A / 230 V /
Potential­free NO contacts max. 3 A / 230 V
13
Steuergerät für Regen­/Windsteuerung /
Control device for rain/wind control unit
14
Netz / Power
15
Relais Kontakt Wind / Relay contact wind
16
Relais Kontakt Regen / Relay contact rain
17
Trafo / Transformer
7
4
ON
OFF
8
5
6
9
LEDs
2
3
W R
2 x 2 x 0.8 mm
+
W R
10
2
