IMPORTANT : THESE INSTRUCTIONS SHOULD BE READ CAREFULLY AND RETAINED FOR FUTURE REFERENCE
Important Safety Advice
When using electrical appliances, basic precautions should
always be followed to reduce the risk of fire, electrical shock,
and injury to persons, including the following:
If the appliance is damaged, check with the supplier before
installation and operation.
Do not use outdoors.
Do not use in the immediate surroundings of a bath, shower
or swimming pool.
Do not locate the heater immediately below a fixed socket
outlet or connection box.
Do not cover the heater. Do not place material or garments on
the heater, or obstruct the air circulation around the heater,
for instance by curtains or furniture, as this could cause
overheating and a fire risk.
The heater carries the Warning symbol, indicating that
it must not be covered.
This appliance is not intended for use by children or other
persons without assistance or supervision if their physical,
sensory or mental capabilities prevent them from using it
safely. Children should be supervised to ensure that they do
not play with the appliance.
Caution: In order to avoid a hazard due to inadvertent resetting
of the thermal cut-out, this appliance must not be supplied
through an external switching device, such as a timer, or
connected to a circuit that is regularly switched on and off by
the utility.
Ensure that furniture, curtains or other combustible material
are positioned no closer than 1 metre from the heater.
In the event of a fault unplug the heater.
Unplug the heater when not required for long periods.
Although this heater complies with safety standards, we do
not recommend its use on deep pile carpets or on long hair
type of rugs.
The appliance must be positioned so that the plug is
accessible.
If the supply cord is damaged it must be replaced by the
manufacturer or service agent or a similarly qualified person
in order to avoid a hazard.
Keep the supply cord away from the front of the heater.
General
Unpack the heater carefully and retain the packaging for possible future
use, in the event of moving or returning the fire to your supplier.
The fire incorporates a flame effect, which can be used with or without
heating, so that the comforting effect may be enjoyed at any time of the
year. Using the flame effect on its own only requires little electricity.
These models are designed to be inset in a fireplace opening or suite. For
fireplace opening requirments see min. dimensions in Fig. 1.
The Deluxe model contains a remote control which is located in a pocket
in the hinged ash-pan flap - see Fig. 4.
Before connecting the heater check that the supply voltage is the same
as that stated on the heater.
Please note: Used in an environment where background noise is very
low, it may be possible to hear a sound which is related to the operation
of the flame effect. This is normal and should not be a cause for concern.
Electrical connection
WARNING – THIS APPLIANCE MUST BE EARTHED.
This heater must be used on an AC ~ supply only and the voltage marked
on the heater must correspond to the supply voltage.
Before switching on, please read the safety warnings and operating
Instructions.
Controls (Standard Models)- see Fig. 2a
The controls are located behind the hinged ash-pan flap - see Fig. 3 & 4.
Note: Actual models shown in Fig. 4 & 5 are Deluxe models.
Flame Effect: Press switch to 'ON' position (a switch is in the 'ON'
position when the red indicator mark on the switch is visible). The flame
effect will now operate.
- 1 -
Heat: You have a choice of low heat 1kW or high heat 2kW output. Both
settings have energy regulated control. In order to operate the heating,
switch must be in the 'ON' position - see Fig 2a.
Low Heat Setting: With switch
' to 'ON'. The 1kW heat output is controlled by the energy regulator - see
'Energy Regulator Operation'.
High Heat Setting: With switches
switch '= = = = = ' to 'ON'. The 2kW heat output is controlled by the energy
regulator - see 'Energy Regulator Operation'.
Controls (Deluxe Models) - see Fig. 2b
The controls are located behind the hinged ash-pan flap - see Fig. 3 & 4.
The main ON/OFF switch must first be turned ON to operate the fire
either manually or by using the remote control. The red indicator mark on
the switch will be visible when it is turned on.
Setting
Flame effect
Flame effect & 1kW heat
Flame effect & 2kW heat
To turn off any of the settings Press the 'O' button again
To increase or decrease the brightness of the flame effect use the
button shown in Fig. 2.
Energy Regulator - see Fig. 2
The Energy Regulator controls the heat output and when adjusted to the
required setting will ensure that the heater will not produce heat
unnecessarily.
The Energy Regulator regulates the heat output according to user needs.
Operate the appliance at full power until the required room temperature
is reached. Set back the regulator until the appliance switches off with
an audible 'click'. This temperature will be kept almost constant by the
energy regulator switching on and off automatically. Please note that the
appliance can only be switched on when the regulator setting is higher
than the room temperature.
Note: Once the Energy Regulator has switched the appliance off it may
take some time before the heater comes back on. This does not mean
that the appliance is faulty.
LED indicators (Deluxe Models only) - see Fig. 6
Three LED's as shown in Fig. 6 are indicating the heat setting for a
couple of seconds every time you change the setting.
One LED means ON (flame effect only, no heat), two LED's means 1kW
heat and all three LED's are lit for full 2kW heat setting.
Remote control (Deluxe Models only) - see Fig. 7
The maximum range of use is 15metres. The buttons on the remote
control have the same function as the switches on the heater. For details
on the functions please refer to the 'Controls' section in this instruction
leaflet.
Warning: It takes time for the receiver to respond to the transmitter.
Do not press the buttons more than once within two seconds for correct
operation.
Battery information (Deluxe Models only) - see Fig. 7
1. Slide open the battery cover on the back of the remote control
2. Install AAA batteries into the remote control
3. Replace the battery cover.
Discard leaky batteries
Dispose of batteries in the proper manner according to provincial and
local regulations.
Any battery may leak electrolyte if mixed with a different battery type, if
inserted incorrectly, if all the batteries are not replaced at the same time,
if disposed of in a fire, or if an attempt is made to charge a battery not
intended to be recharged.
in the 'ON' position, press switch '– – – – –
and '– – – – – ' in the 'ON' position, press
Operation Indication
Press the 'I' button once Top neon
Press the 'I' button again Top & middle neon
Press the 'I' button again All 3 neons
