Sound-controlled mode
In sound-control mode, the scenes stored in a memory bank will be synchronized with music pulses via the
internal microphone.
1. Switch to sound-controlled mode with the RUN MODE button.
2. Call the desired chase with the CHASE buttons.
3. The sensitivity of the sound control is adjustable between 0-100 % with the buttons ⊳ and
4. Use the FADE TIME control to adjust the fade time.

Strobe effect

By keeping the STROBE button (17) pressed you activate the strobe effect. The green LED lights up. Strobe can
be used in all modes and means that the fixtures start to flash. You can adjust the speed with the fader (9).

Blackout

The BLACKOUT button (16) remains active in each mode. If you press (16) all fixtures go out (standby mode).
The LED of the button flashes. You can go back to the previous state by pressing the Blackout button again.

Data backup

All settings of a light show, i.e. DMX settings, scenes and chases can be stored on a USB memory device and
recalled later. 16 memory banks on the buttons FIXTURE 1-16 are available.
1. Connect a USB memory device to the controller's USB port.
2. Keep the button RUN MODE pressed and simultaneously press the button ⊳. The display indicates "Save ".
3. Select a memory bank with one of the FIXTURE buttons.
Each memory bank must be stored separately. If the control LED of a FIXTURE button lights, this memory
bank has been stored on the USB memory device before.
The data will be stored in the folder "led_operator" located on the root directory of the USB memory device. A
file with the extension "PRO" will be created for each memory bank. You should not make any changes to the
default folder. Otherwise the controller cannot the reload the data later.
4. After completing the data backup (approx. 20 seconds), the display shortly inserts "ok".
5. Turn the controller off and on again. The data backup procedure is complete.

Data import

1. Connect a USB memory device to the controller's USB port.
2. The files to be imported must be stored in the folder "led_operator" located on the root directory of the USB
memory device.
3. Keep the button RUN MODE pressed and simultaneously press the button
The control LED of a FIXTURE button lights, when data is available on the USB memory device for this
memory bank.
4. Select the file to be loaded with the FIXTURE buttons.
5. After successful completion of the data import, the display shortly inserts "ok".
6. Turn the controller off and on again. The data import procedure is complete.
18 • EN
.
. The display indicates "Load".
