The chaser with flashing Playback-LED can be edited. Adjust the desired speed via the Wait Time-Fader or
the Tap/Del-buttons. Select the next chaser by pressing and holding the respective Playback-button (LED
must flash).
Switch the speed-range
The speed-range can be switched between 0-10 minutes and 0-2 minutes:
Switch the controller off and on again.
Press and hold the Program-button and the Up-button (0-2 min) or Down-butoon (0-10 min).
Delete a step in a chaser
Press the Mode Program-button, until the Program-LED is lit.
Push the Masterfader to maximum.
Select the desired bank via the respective Chase-button and press the desired Flash-button in the Playback-
section.
Press the Up/Down-button in order to call up the desired step.
Press the Tap/Del-button in order to delete the step. All LEDs shortly flash.
Press and hold the Program-button in order to leave the programming mode.
Add a step to a chaser
Press the Mode Program-button, until the Program-LED is lit.
Push the Masterfader to maximum.
Select the desired bank via the respective Chase-button and press the desired Flash-button in the Playback-
section.
Press the Insert/Clear-button, until the LED is lit.
Press the Up/Down-button in order to select the desired position.
Push channel-faders to the desired setting.
Press the Program-button. All LEDs shortly flash. The step is now inserted in the chaser.
Press and hold the Program-button in order to leave the programming mode.

Clear memory

Switch the controller off.
Press and hold the Program-button and the Up-button (0-2 min) or Down-butoon (0-10 min).
Press and hold the Run Mode, Program-button and Tap/Del-button.
Switch the controller on. The display shows "Reset Default, Please wait..." Let the three buttons loose. After
some seconds, the display shows "Reset OK" and the memory is cleared.

Data backup

The Flash-buttons in the Channels-section can be used for saving file 1-24 on a USB media.
Insert the USB media into the USB socket.
Press and hold the Run Mode-button and the Up-button.
Press the desired Flash-button.
The display shows the progress of data saving. As soon as data saving is finished, the display shows "File
Save OK?".
Data loading
Insert the USB media into the USB socket.
Press and hold the Run Mode-button and the Down-button.
Press the desired Flash-button.
The display shows the progress of data loading. As soon as data saving is finished, the display shows
"Loader file OK?".
