Table of Contents
Introduction ..............................................................................................................26
Intended Use ............................................................................................................27
Product description ..................................................................................................27
Table of Contents......................................................................................................28
Explanation of symbols ............................................................................................28
Safety instructions and danger warnings..................................................................29
Connection and control elements ............................................................................32
Setting up the device ................................................................................................36
Connection ................................................................................................................37
Connection of inputs ............................................................................................37
Connection of outputs ..........................................................................................38
Connection of fader-start outputs ............................................................................39
Connection of voltage supply ..................................................................................39
Commissioning ........................................................................................................41
Switching mixer on/off ..........................................................................................41
Select input ............................................................................................................41
Set input level. ......................................................................................................42
Set output level ......................................................................................................42
Pre-listening ..........................................................................................................42
Superimposing/people ..........................................................................................43
Setting microphone ..............................................................................................43
Use of sound control ............................................................................................43
Cross-start feature ................................................................................................43
Servicing and maintenance ......................................................................................44
Disposal ....................................................................................................................44
Elimination of disturbances ......................................................................................45
Technical data ..........................................................................................................47
Explanation of symbols
The symbol with the lightening in the triangle is used when your health
is at risk, e.g. through an electric shock.
The exclamation mark in a triangle indicates to you particular risks in
handling or operating.
The hand indicates important tips and supplementary comments
about use.
28
Elimination of disturbances
By purchasing the "Mini DJ-Mixer McCrypt DJ-50", you have acquired a product
that has been designed according to the state of the art and is operationally safe.
However, problems and malfunctions can occur.
Therefore we should like to describe here how you can eliminate possible distur-
bances.
Always observe the safety instructions!
Problem
Possible cause
Device does not
The plug-in power unit has
work after the
not been inserted correctly
mains switch
in the socket or the plug-in
POWER (24)
power unit has not been
does not was
correctly inserted in
switched on:
the mixer.
The operating
The mains socket is not being
display (3)
supplied with current
does not light up.
The operating
No input signal
display lights up
Input connected incorrectly
but no tome can
or not at all
be heard.
Input level set incorrectly
MASTER slide control is in
position "0".
Channel faders (14) are in
position "0"
No signal can be
Downstream device not
heard although
switched on or
the level display
incorrectly set
displays a signal
Output incorrectly connected
or not at all
Elimination of the fault
Connect the power cable
correctly.
Check the mains socket
Check the source of signal
Connect input correctly
Set level using the control
"GAIN" (2) as described
Set control "MASTER" (3)
correctly
Set channel faders correctly
Check downstream device,
select correct input on the
amplifier
Connect output as described
45
