Table of Contents

Introduction ..............................................................................................................30
Intended Use ............................................................................................................31
Product description ..................................................................................................31
Table of Contents......................................................................................................32
Explanation of symbols ............................................................................................32
Safety instructions and danger warnings..................................................................33
Connection and operating elements ........................................................................36
Setting up the device ................................................................................................42
Connection ................................................................................................................43
Connecting the inputs............................................................................................43
Connecting the outputs ........................................................................................44
Connecting the voltage supply ..............................................................................45
Commissioning ........................................................................................................47
Switching mixer on/off ..........................................................................................47
Select input ............................................................................................................48
Set input level. ......................................................................................................48
Set MASTER output level ......................................................................................48
Listening-in, pre-listening ......................................................................................49
Setting DJ microphone ..........................................................................................50
Cross-fading/mixing ..............................................................................................50
Equaliser feature ....................................................................................................50
Servicing and maintenance ......................................................................................52
Disposal ....................................................................................................................52

Replacing the fuse ....................................................................................................53

Elimination of disturbances ......................................................................................53

Technical data ..........................................................................................................55

Explanation of symbols

The symbol with the lightening in the triangle is used when your health
is at risk, e.g. through an electric shock
The exclamation mark in a triangle indicates particular risks in handling
or operating.
The hand indicates important tips and supplementary comments
about use.
32
Downloaded from www.Manualslib.com manuals search engine
Replacing the Fuse
Fuses may only be replaced when the mains plug has been pulled
out and with fuses of the same type, the same triggering charac-
teristics and the same nominal power. The use of "fixed", repaired
fuses or bridging the fuse bracket is not permitted.
• Switch off the mixer and all connected devices.
• Unplug the mains plug from the mains socket!
• Open the fuse compartment (30) with the aid of a screwdriver turning it in the anti-
clockwise direction.
• Replace the defective fuse with a new 315mA delay-action / 250V // 5x20mm
glass-tube micro-fuse.
• Close the battery compartment again.
Elimination of disturbances
By purchasing the "Mini DJ-Mixer McCrypt SM-3090/2", you have acquired a prod-
uct which has been designed according to the state of the art and which is opera-
tionally safe.
However, problems and malfunctions may occur.
Therefore, we should like to describe here how you can eliminate any possible dis-
turbances.
Always observe the safety instructions!
Problem Possible cause
Device does not The mains plug has not
work after the been plugged into the
on/off switch has socket correctly
been switched on: Fuse defective.
The operating No input signal
display lights up Input connected
but no tone can incorrectly or not at all
be heard. Input level set incorrectly
MASTER fader is in
position "0".
Channel faders are in
position "0"
Elimination of the fault
Connect the mains plug
correctly.
Replace fuse.
Check the signal source
Connect input correctly
Set level using the PRE-SET
control as described
Set MASTER fader correctly
Set channel faders correctly
