Problem Possible cause
No sound can No earth connection between
be heard. the devices
A cable is defective
A buzz loop arises between
the connected devices
A channel does Connection cable has
not work worked loose.
The balance control on the
amplifier is out of adjustment
Tone is distorted Mixer output is incorrectly set
or the connected amplifier is
overmodulated
Connected device does not
adhere to the required
specification for a cinch
connection or does not
possess the appropriate
connections
Control GAIN (2) is incorrectly
adjusted, the mixer is
overmodulated
Repairs other than those just described should only be carried out
by an authorised specialist.
46
Elimination of the fault
Make an earth connection
between the devices through
the screw terminal GND (19)
Replace cable
Connect signal earth by
means of specially
earth-insulated cable.
Check connections between
the devices
Set balance control on
amplifier
Set mixer output as
described
Use device with the
appropriate connection
Set mixer input as described

Intended Use

The range of use of the "Mini DJ-Mixer McCrypt DJ-50" includes use in music cen-
tres in the home and semi-professional environments.
The device is used to mix and regulate low-level audio signals. The device is there-
fore connected between the audio signal source to be regulated and an audio ampli-
fier.
It may only be used in closed, dry rooms. Contact with moisture must be avoided at
all times.
Use other than that described above will lead to damage of the product and may
involve additional risks such as short circuits, fire, electrical shocks etc.
The product must not be altered or converted in any way. Do not open the housing!
The safety instructions have to be observed without fail!

Product description

• 2-channel mixer
• 1 microphone input
• 2 stereo record-player inputs
• 2 stereo inputs for CD players, cassette decks, tuners etc.
• 1 stereo MASTER output
• 1 Stereo RECORD output for recording the mixer signal
• 2 "American Audio Q series" fader start outputs
• control for trebles and basses
• earphone connection with controllable volume
• LED recording level display
• Cross-fader feature
• input level control for each channel
• Mute feature for switching mixer on/off
