Operating elements

The Ace Matte Box has been designed to support a range of DSLR and HDV cameras. The Ace
Matte Box embodies adjustable top and side flags and attachment points, two accessory bars,
two filter stages, rear clamping interface and a rod bridge.
Top flag
Filter frame
release button
Accessory bar
Neoprene rings
Fig. 1 Operating elements
Support rod clamp
Side flag clamp
Filter frames
-4-
Top flag clamp
Rear clamping
interface
Rod bridge
Side flag
