Table of contents
Safety information
Refer to the installation user manual for general safety information, hazard descriptions and
precautionary labels descriptions.
User interface and navigation
Keypad description
Refer to
Figure 1
for the keypad description and navigation information.
Figure 1 Keypad description
2 Navigation keys RIGHT, LEFT: switch
measurement displays, select options, navigate
data entry fields
3 Navigation keys UP, DOWN: scroll menus, scroll
measurement channels, enter numbers and letters
4 Home: go to the main measurement screen
5 Enter: confirm and open sub-menus
Display description
Figure 2
for the measurement screen descriptions. Refer to
descriptions.
6 Diag: enter the DIAG/TEST MENU
7 Cal: enter the CALIBRATE MENU
8 Back: go back to the previous menu
9 Menu: select options from the analyzer main menu
Figure 3
for the system status
English 3
