4. CTCSS code: 62.5-254.1 total 51 groups. DCS code: 000N-777I total 1024 groups, N is positive
code, I is inverse code. Press V/M to choose positive code or inverse code.
5. Press [UP]/[DN] key or any other key except volume knob to exit.
» Under channel mode, this operation can be temporarily used by user. Once the radio is
turned off or switched to another channel, the temporary setting will be erased. If the ch-
annel setting programmed for valid, the temporary setting will keep valid until next change,
turn off radio or switch to another channel, the temporary setting will not changed.
CTCSS Scan
Separately short press [FUN] key and [SOL] key to enter CTCSS/ DCS encode/decode menu,
repeatedly short press [SQL] key until LCD displays CT, short press [SCA] key can enter CTCSS
scan mode. Short press [UP] or [DN] key can change the scan direction, Once finding a matching
CTCSS signaling, it will stop for 5S then scan again. Press any key to exit.
DCS Scan
Separately short press [FUN] key and [SQL] key to enter CTCSS/ DCS encode/decode menu,
repeatedly short press [SQL] key until LCD displays DCS, short press [SCA] key to enter DCS scan
mode. Short press [UP] or [DN] key can change the scan direction. Once finding a matching DCS
signaling, it will stop for 5S then scan again. Press any key to exit.
Keypad Lockout
Avoiding unintentional operation, this function will lock the keys except [PTT] key and [FUN] key.
1. Short press [FUN] key the LCD displays F icon, press [VOL] key again the LCD displays Lock
means the keypad is locked.
2. Repeate above operation, when Lock icon disappears, means the keypad is unlocked.
Function Menu
1. Hold [FUN] key for over 2S to enter function menu.
2. Short press [UP]/[DN] or turn VOL knob to switch menu option.
3. Short press [VOL] key to enter 2nd level menu setup
4. Short press [UP]/[DN] key or turn VOL knob to choose current setting.
5. Short press any key to store and exit.
» There are 2 part of function menu: part 1, Menu No. 1-10 channel function menu. part 2
Menu No. 11-20 function menu. Part 1 will automatically hide in channel mode by
program software.
Signaling Combination Setup
Enter No. 01 function menu, the LCD displays "SKP". This function can improve the level of
blocking irrelative signals.
SQ: You can hear the calling when receive a matching carrier.
CTC: You can hear the calling when receive a matching carrier and CTCSS/DCS signaling.
Default: SQ
» This setting is valid only when CTCSS/DCS signaling added.
HIGH/MID/LOW Power Selection
Enter No. 02 function menu , the LCD displays "POW". This function use to control transmit power
level.
HI: Transmit with high power.
MI: Transmit with middle power.
11
LO: Transmit with low power.
Default: HI.
Band-width Selection
Enter No 03 function menu , the LCD displays "BNAD".
Select suitable bandwidth in accordance with different local conditions
WIDE: band width is 25k(Wide band)
NAR: band width is 12.5k(Middle band)
Default: WIDE.
Busy Channel Lockout
Enter No 04. function menu , the LCD displays "BUSY".
BCLO is to disable transmitting while RX signal is received. Once the channel is busy and you
press [PTT], the radio will beep as warning and get back to receiving.
BU: Enable BCLO, Carrier lockout, transmitting is inhibited when current channel receives a
matching carrier; press [PTT] to emit error voice prompt and back to receiving mode.
RL: Enable BTLO, transmitting is inhibited when current channel receives a matching carrier but
dis-matching CTCSS/DCS. Press [PTT] key to emit error voice prompt and back to receiving
mode.
OFF: BCLO is disabled. It can transmit in any receiving status.
Default: OFF.
Editing Channel Name
Enter No.05 function menu , the LCD displays "NAME".
1. Press [UP]/[DN] or turn VOL knob to choose character for present cursor location.
2. Press [V/M] key to confirm and move to next character edit.
3. Press [FUN] key to return to last character edit.
» In Frequency (VFO) mode ,this function will be auto-hidden.
TX OFF
Enter No.06 function menu , the LCD displays: "TX".
This function use to disable the transmitting for current channel.
ON: TX allowed, press [PTT] to transmit.
OFF: TX not allowed, press [PTT] will emit a wrong report.
Default: ON.
Reverse Frequency
Enter No.07 function menu , the LCD display "REV".
When turn on this function, the TX frequency turns to RX frequency & RX frequency changes to TX
frequency. The signaling will reverse if CTCSS/DCS signaling existed in this channel.
ON: Turn on reverse function
OFF: Turn off reverse function
Default: OFF.
Talk Around
Enter No.08 function menu , the LCD displays "TALK".
This function enable direct communication with other radios in case the repeater is not activated or
when out of the repeater range. The transceiver will transmit by RX frequency with its CTCSS/DCS
signaling.
ON: Turn on talk around function
OFF: Turn off talk around function
