Step 2: Prepare Bresle Method Patch
Option A: DeFelsko PosiPatch
a) Turn the PosiPatch and magnetic ring upside down. Place the
PosiPatch into the magnetic ring ensuring the arrows align with
the injection port. Do not touch the PosiPatch's interior.
b) Carefully place the magnetic ring on the steel surface. When used
on vertical surfaces, position the port between the 2 o'clock and
10 o'clock points before attaching the ring to the surface.
c) Slowly inject 3.0ml of DI water into the port using the plastic
dispensing tip. The air within the PosiPatch automatically escapes
through the air-permeable membrane.
a)
When used on horizontal surfaces, fully insert the dispensing tip into
the PosiPatch. On vertical surfaces, insert the dispensing tip only as
far as is needed to see the tip inside the PosiPatch.
Option B: Bresle Method DeFelsko Patch (or equivalent)
a) Remove the backing and foam center from the patch, taking care
not to touch the interior surface.
b) Press the patch firmly onto the surface making sure most of the air
escapes.
c) Pierce the top of the patch at the foam perimeter, allowing the
needle to penetrate into the center of the patch.
a)
b)
b)
4
c)
c)
