The PosiTector SST powers-up when the center navigation
button is pressed. To preserve battery life, the Gage
powers down after approximately 5 minutes of no activity (15
minutes while in Bresle Mode, pg. 9). Alternatively, select
Power Off from the menu. All settings are retained.
Gage functions are menu controlled. To access the Menu,
power-up the gage, then press the center navigation button.
To navigate, use the Up and Down buttons to scroll vertically and
to SELECT.
Previous Page
(Exit)
Access the Menu
(Center/Select)
When powered-up, the PosiTector automatically
determines which probe is attached and does a self-check.
To disconnect a probe from a body, slide the plastic probe
connector horizontally (in the direction of the arrow) away
from the body. Reverse these steps to attach a different
probe. It is not necessary to power-down the Gage when
switching probes.
Additionally, the PosiTector gage body accepts a wide variety of
probe types including magnetic, eddy-current and ultrasonic coating
thickness, surface profile, environmental, hardness, salt contamination
and ultrasonic wall thickness probes. See www.defelsko.com/probes
PosiTector SST probes consist of a purpose-built
test cell, optimized for the range, resolution and
test volume of the Bresle Method. Conductivity
measurements are compensated to 25°C (77°F)
using a built-in temperature sensor, and the
sample temperature is recorded for each
measurement. The probe can be used as a
conventional conductivity meter by unchecking
Bresle Mode (pg. 9).

Basic Operation

Menu Operation

Next Page
Up
Down
Probes
( + )
Press the
pages in a multipage menu.
Press the (-) button to return
to the previous menu or page.
Select Exit to exit from any menu.
2
button to switch
Test
Cell
