OPERATION

After connecting the device to the mains it is ready for operation. The display indicates the last operating
mode. The operating modes can be selected by means of the display and the control buttons. All settings
remain stored even if the device is disconnected from the mains. The device can be operated in stand-alone
mode via the control board or in DMX-controlled mode via any commercial DMX controller.

Control Board

The Control Board offers several features: you can simply set the starting address, run the pre-programmed
program or select a DMX channel mode.
Browse through the menu by pressing Menu. Press Enter in order to select the desired menu. You can
change the selection by pressing Up or Down. Press Enter in order to confirm. You can leave every mode by
pressing Menu. The functions provided are listed in the following sections.
Default settings shaded.
Menu Sub menu
RED
GREE
BLUE
STATIC WHIT
A
UV
STRB
ADDRESS
AUTO
AUTO
SP
SOUND
MODE
DIMCurve
BACK
SET
DMXSate
Sensor
Version
TEMP
RESET
Interconnecting several devices (master/slave operation)
Several devices may be interconnected (max. 32). Then all slave units can be synchronized and controlled
with the master unit without the need for a DMX controller. The devices must be set to the corresponding
operating modes.
1 Configure all slave units before connecting the master unit: Set the start address 001 for all slave
devices.
2 Connect the DMX output of the master unit to the DMX input of the first slave unit. Then connect the
DMX output of the first slave unit to the DMX input of the second slave unit, etc. until all units have been
connected in a chain. Make sure the master unit is the first in the chain. Do not connect a DMX controller
to the DMX input of the master unit.
3 Set the master unit to the desired operating mode. The interconnected devices will now operate in sync.
Description
000-255
000-255
000-255
Dimmer intensity of LED colors:
000-255
red, green, blue white, amber and UV
000-255
000-255
Strobe effect 0 – 20 (increasing)
00-20
DMX address setting
001-512
01-20 Automatic programs
Speed (increasing)
00-99, 50
01 Sound controlled program (color change)
Sound controlled program (strobe)
02
Setting DMX channel mode/
6CH/11CH/24CH/
number of DMX channels
41CH/77CH
Dimmer curve
DIMMER1: Linear dimmer curve
DIMMER1-4 DIMMER2: Exponential dimmer curve
DIMMER3: Inverse exponential dimmer curve
DIMMER4: S-curve
Display shutoff
ON/OFF
ON: Shuts off the display after about 60 seconds
OFF: Display is always on, does not switch off
Mode when there is no DMX signal
ON: Holds the last signal when no DMX signal is
ON/OFF received
OFF: Switches off the LEDs when no DMX signal is
received
Microphone sensitivity
000-100
V.X.X Software version
Temperature inside of the device
XX°C
Restore the factory settings
