DESCRIPTION OF THE DEVICE

1 2 3
(1) LED/lens
(2) Safety eyelet
(3) Mounting bracket/foot
(4) Control Board
(6) Up button
(8) Down button
10 11
4 5 6 7
(10) Power input
12 13
(11) DMX input
(12) Power output
PUSH
(13) DMX output
8 9
(5) Menu button
(7) Display
(9) Enter button
