13 Frequencies (typical)

13.1

Pulse counter

HTL level
AC supply
DC supply 12V
DC supply 24V
Add
Sub
55 kHz
Cnt.Dir
Up.Dn
20 kHz
Up.Up
Quad
28 kHz
Quad 2
10 kHz
Quad 4
A/B
(A-B)/A
5V level
typ. Low 1,0 V
typ. High 4,0 V
Add
Sub
9 kHz
Cnt.Dir
Up.Dn
9 kHz
Up.Up
Quad
9 kHz
Quad 2
9 kHz
Quad 4
A/B
(A-B)/A
www.kuebler.com
typ. Low 2,5 V
typ. High 22 V
typ. Low 2 V
typ. High 10 V
typ. Low 2,5 V
typ. High 22 V
AddAr AddTot
SubAr
AddBat
1,5 kHz 1,6 kHz
1,5 kHz 1,6 kHz
0,7 kHz 0,7 kHz
0,7 kHz 0,7 kHz
29 kHz
AddAr AddTot
SubAr
AddBat
1,3 kHz 1,6 kHz
1,3 kHz 1,6 kHz
0,5 kHz 0,7 kHz
0,5 kHz 0,7 kHz
9 kHz
13.2

Frequency meter

HTL level
AC supply
DC supply 12V
DC supply 24V
5V level
HTL
65 kHz
A
A – B
A + B
59 kHz
A / B
(A-B)/A
30 kHz
Quad
NOTE: Switching levels of the input
Switching levels with AC supply:
HTL level Low:
High:
5V level Low:
High:
Switching levels with DC supply:
HTL level Low:
High:
5V level Low:
High:
typ. Low 2,5 V
typ. High 22 V
typ. Low 2 V
typ. High 10 V
typ. Low 2,5 V
typ. High 22 V
typ. Low 1,0 V
typ. High 4,0 V
5V
9 kHz
9 kHz
9 kHz
0 .. 4 VDC
12 .. 30 VDC
0 .. 2VDC
3,5 .. 30 VDC
0 .. 0,2 x UB
0,6 x UB .. 30 VDC
0 .. 2 VDC
3,5 .. 30 VDC
