10.7

Supply voltage

AC supply: 90 ... 260 V AC / max. 8 VA
50/ 60 Hz
ext. fuse protection: T 0.1 A
DC supply: 10 ... 30 V DC/ max. 1.5 W
reverse polarity protection
ext. fuse protection T 0.2 A
10.8

Sensor supply voltage

AC supply: 24 V DC ±15%, 80 mA
DC supply: max. 80 mA, external voltage
supply is connected through
10.9 Climatic Conditions
Operatin g temperatur e: -20°C .. +65°C
Storage temperatur e:
Relative hum idity: RH. 93% at +40°C,
Altitude:

10.10 EMC

Noise immunity: EN61000-6-2
with shielded signal and
control cables
Noise emission: EN55011 Class B
10.11 Device safety
Design to: EN61010 Part 1
Protection Class: Class 2
Application area: Soiling Level 2

10.12 Mechanical Data

Housing: Panel-mount housing
to DIN 43 700, RAL 7021
Dimensions: 48 x 48 x 91 mm
Panel cut-out: 45
Installation depth: ca. 107 mm incl. terminals
Weight: ca. 125 g
Protection: IP 65 (front)
Housing material: Polycarbonate UL94 V-2
Vibration resistance: 10 - 55 Hz / 1 mm / XYZ
(EN60068-2-6): 30 min in each direction
Shock resistance 100G / XYZ
(EN60068-2-27): 3 times in each direction
(EN60068-2-29): 10G/6 ms/XYZ 2000 times in
each direction
Cleaning: The front of the unit should
only be cleaned using a soft
damp (water!) cloth.

10.13 Connections

Supply voltage and outputs:
Plug-in screw terminal, 7-pin, RM5.08
Core cross section, max. 2.5 mm²
Plug-in screw terminal, 5-pin, RM 3.81
Core cross-section, max. 1.5 mm²
Signal and control inputs:
Page 18
-25°C .. +75°C
non-condensing
to 2000 m
+0,6 +0,6
x 45 mm
Plug-in screw terminal, 8-pin, RM 3.81
Core cross-section, max. 1.5 mm²

11 Scope of Delivery

Preset counter
Mounting clip
Instruction manual

12 Ordering codes

6.924.X10X.XXC
2 additional relay outputs
Input trigger levels
Supply voltage
LCD version
Outputs
Front
0 = Standard (HTL)
A = Fixed level
0 = 90 .. 260 VAC
3 = 10 .. 30 VDC
0 = no backlighting
1 = green backlighting
2 = LED Look
3 = Multicolour
0 = Relays
0 = Kübler version
A = Neutral version
*Fixed level (Low 0 ... 2 V DC,
High 3,5 ... 30 V DC)
