Operating instructions
Electronic totaliser
C C O O D D I I X X 5 5 4 4 0 0
1. Description
• 6-digit adding counter with RESET function
• Red LED display, character height 14 mm
• Display range 0..999 999
• Leading zeros suppression
• Programming via two setting keys on the front
side
• During programming, the display guides the
user with text prompts
• With AC power supply: sensor supply
voltage: 24 V DC/±15 %/100 mA
1.1 Preface
Please read this instruction manual carefully
before installation and start-up.
Please observe all warnings and
advices, both for your own safety
and for general plant safety. If the
device is not used in accordance
with this instruction manual, then the intended
protection can be impaired.

1.2 Safety Instructions and Warnings

Please use the device only if its technical condi-
tion is perfect. It should be used only
for its intended purpose. Please bear
in mind safety aspects and potential
dangers and adhere to the operating
instructions and to this addendum at
all times. The safety standards in force for electri-
cal installations are also to be adhered to.
1.3 Use according to the intended
purpose
The application area for this device lies in indus-
trial processes and controls, in the fields of manu-
facturing lines for the metal, wood, plastics,
paper, glass, textile and other like industries with
a degree of contamination of 2. Over voltages at
the terminals of the device must be kept within
the limits of Over voltage Category II. The device
is not suitable for use in hazardous areas and for
areas excluded from EN 61010 Part 1. The
device may only be operated indoors as a panel-
mounted device. However, in certain conditions,
an outdoor operation is also allowed. It may be
operated up to an altitude of 2,000 m. Use for
any purpose over and beyond this will be
deemed as not in accordance with its intended
purpose.
If the device is used to monitor machines or
processes in which, in the event of a failure of
the device or an error made by the operator,
there might be the risk of damaging the
machine or causing an accident to the opera-
tors, then it is your responsibility to take the
appropriate safety measures.

1.4 Mounting in a control panel

Mount the device away from heat sources and
avoid direct contact with corrosive
!
liquids, hot steam or similar. When
mounting the device, make sure it
is sufficiently cooled.

1.5 Mounting instructions

– Remove the mounting clip from the device.
– Insert the device from the front into the panel
cut-out, ensuring the front-panel gasket is
correctly seated.
– Slide the fixing clip from the rear onto the
housing, until the spring clamps are under
tension and the upper and lower latching
lugs have snapped into place.

1.6 Electrical Installation

This device is powered by the mains voltage! It
must be disconnected from the power supply,
before any installation or maintenance work is
carried out. AC-powered devices must only be
connected to the low-voltage net-
!
work via a switch or circuit breaker.
Installation or maintenance work
must only be carried out by quali-
fied personnel.
– Correct operation of the device requires the
mandatory use of the appropriate external
safety fuse. Advice concerning the recom-
mended fuse protection can be found in the
relevant instruction manual. In order to
respect the fire protection regulations, 8
1
