INTEGRAL POWER II
Mark and make the cuts and boreholes (protect
3
the sharp edges with anti-oxidant).
Position the seal joint, side seals and front
4
seal inside the compact as shown.
a
b
c
Seal joint
Side seals
Front seal
Ø 7 (6)
OPERATION DIRECTION
b
13
EN
Ø 35
a
