Cutting along fences/foundations
Approach wire mesh fences, lath fences, natural stone
walls and foundations slowly so that you can cut close
to them without striking the obstacle with the line. If, for
example, the line strikes stones, stone walls or founda-
tions, it will wear or fray. If the line strikes wire fencing, it
will break.
Trimming around trees
When trimming around tree trunks, approach slowly so
that the line does not strike the bark. Walk around the
tree, cutting from left to right. Approach grass or weeds
with the tip of the line and tilt the line spool forwards
slightly.
Warning! Take extreme care during mowing work. When
doing such work keep a distance of 30 meters between
yourself and other people or animals.
Mowing
When mowing, you want to cut all the vegetation down
to the ground. To do this, set the line spool at an angle of
30° to the right. Place the handle in the required position.
Remember the increased risk of injury to the user, watch-
ers and animals, and the danger of damaging property
due to objects (for example stones) being thrown.
Warning! Do not use the equipment to remove objects
from footpaths, etc. The equipment is a powerful tool and
can throw small stones and other objects a distance of
15 meters or more, causing injuries and damage to cars,
houses and windows.
Jamming
If the cutting blade jams as a result of attempting to cut
vegetation that is too dense, switch off the engine imme-
diately. Remove the grass and scrub from the equipment
before you restart it. Fig. 42
Preventing recoil
When you work with the blade, there is a risk of recoil if
it strikes solid objects such as tree trunks, branches, tree
stumps, stones or the like. This will throw the equipment
backwards in the direction opposite to the rotation of the
tool. This can cause you to lose control of the equipment.
Do not use the blade near fences, metal posts, boundary
stones or foundations.
26 GB

10. Maintenance

Before performing any maintenance or cleaning work, al-
ways turn off the engine and pull out the spark boot
1. Do not spray the unit with water. It damages the en-
gine.
2. Clean the unit with a cloth, hand brush, etc.
Maintenance schedule
12 hours of 24 hours of
use
Air filter clean
Spark plug check
Expert inspection is required:
• If the brush cutter strikes an object.
• If the motor stops suddenly
• If the blade is bent (do not align!)
• If the gears are damaged.
Replacing the line spool/cutting line Fig. 35 - 39
1. Dismantle the line spool (1) as described in section
8.4 Assembly. Press the spool together and remove
one half of the housing. Fig. 35
2. Take the spool plate out of the line spool housing.
Fig. 36
3. Remove any remaining cutting line.
4. Place the new cutting line in the center and hang the
loop which has formed into the recess in the spool split-
ter. Fig. 37
5. Wind the line onto the spool counter-clockwise and
under tension. The spool splitter will separate the two
halves of the line. Fig. 38
6. Hook the last 15cm of the two ends of the line onto the
opposite lying line holders of the spool plate. Fig. 39
7. Thread the two ends of the line through the metal
eyelets in the line spool housing .
8. Press the spool plate into the line spool housing.
Fig. 36
9. Pull the two line ends sharply to release them from
the line holders.
10. Join the housing parts together again. Fig. 35
11. Cut the excess line to a length of around 13cm. This
will reduce the load on the engine when starting and
warming up.
12. Remount the line spool (see section 8.4). If you are
replacing the complete line spool, skip points 3-6.
Grinding the safety hood blade
The safety hood blade can become blunt over time.
• When you notice this, undo the screw holding the
safety hood blade on the safety hood.
• Clamp the blade in a vise.
• Sharpen the blade with a fl at fi le and make sure that
the angle of the cutting edge is not altered in the pro-
cess. File in one direction only.
Replacing and resharpening the cutting blade at the end
of the mowing season always resharpen the cutting blade
or, if required, replace the cutting blade with a new one.
plug.
36 hours of
use use
clean replace
clean replace
