while the respective orange colour lid opener is pressed with a
little screwdriver.
The Tester is now activated by pressing the impulse button.
Simultaneously the tester is pressed on the front panel to the
bonding surface. The green LED blinks. If the glass break
detector is a normally-closed version, the red LED works as an
activity indicator and goes on as soon as the glass break
detector releases.
If on the other hand in the test specimen it is connected to a
normally-opened version, the red LED lights before and stops if
the glass break detector releases.
The tester can also be used for testing of glass break detectors
with external power supply (for example, glass break detector
with relay exit). The alarm output can be tested in this case as
a 4-wire alarm zone (for example, continuity tester).
Specifications
Operational Voltage
Current consumption at pressed
push button
Current consumption at pressed
push button after automatic
switching off
Battery
Battery life
System indicator
Battery indicator
Contact base
Piezo control
Ultrasonic radiation
Glass break detector connection
Housing dimensions (L x W x D)
Weight (with battery)
Casing Material
Colour
Temperature range
Protection type
Additional features
•
Automatic switching off: If push-button is pressed longer
than 10 s.
•
Battery indicator: Red LED blinks, if battery voltage falls
under approx. 7 V.
•
Glass break detector connection: 2 wire spring loaded
clamps for glass break detector function test; internal
resistance of the 9 V exit: 1 kΩ.
•
Glass break detector function test indicator: Red LED
lights if the glass break detector resistance is lower than
9 kΩ. Red LED lights, if the glass break detector
resistance is higher than 10 kΩ.
2 / 10
6 to 10 V DC
Approx. 60 mA
Approx. 1 mA (stand-by)
9 V
Approx. 8 hours operating time, or
3000 activities (each 10 s long)
Green LED blinks at pushed
button mode, approx. 10 s long
(active time)
Red LED blinks, if battery voltage
falls under approx. 7 V
Piezo ceramic on aluminum plate
130 to 138 kHz, pulsed in approx.
300 V amplitude
Pulse approx. 0,8 W
2 wire spring loaded clamps for
glass break detector function test/
internal resistance of the 9 V
output: 1 kΩ
120 x 60 x 25 mm
Approx. 150 g
ABS
Black
−10 to + 60°C
VdS-environmental class II; IP 40
Regulatory information
Manufactured for
UTC Fire & Security Americas Corporation, Inc.
3211 Progress Drive, Lincolnton, NC, 28092, USA
AUTHORIZED EU REPRESENTATIVE:
UTC Fire & Security B.V.
Kelvinstraat 7, 6003 DH Weert, Netherlands
Product warnings
THESE PRODUCTS ARE INTENDED FOR SALE
and disclaimers
TO AND INSTALLATION BY QUALIFIED
PROFESSIONALS. UTC FIRE & SECURITY
CANNOT PROVIDE ANY ASSURANCE THAT
ANY PERSON OR ENTITY BUYING ITS
PRODUCTS, INCLUDING ANY "AUTHORIZED
DEALER" OR "AUTHORIZED RESELLER", IS
PROPERLY TRAINED OR EXPERIENCED TO
CORRECTLY INSTALL FIRE AND SECURITY
RELATED PRODUCTS.
For more information on warranty disclaimers and
product safety information, please check
https://firesecurityproducts.com/policy/product-
warning/
Certification
European Union
UTC Fire & Security hereby declares that this
directives
device is in compliance with the applicable
requirements and provisions of the Directive
2014/30/EU and/or 2014/35/EU. For more
information see www.utcfireandsecurity.com or
www.interlogix.com.
2012/19/EU (WEEE directive): Products marked
with this symbol cannot be disposed of as
unsorted municipal waste in the European Union.
For proper recycling, return this product to your
local supplier upon the purchase of equivalent
new equipment, or dispose of it at designated
collection points. For more information see:
www.utcfssecurityproducts.eu/recycle/
Contact information
www.utcfireandsecurity.com or www.interlogix.com
For customer support, see www.utcfssecurityproducts.eu
DE: Installationsanleitung
Bezeichnung
Das Glasbruchsensor-Prüfgerät GMP 3 wurde zum Erzeugen
einer Test-Glasbruchfrequenz konzipiert, um die Funktion von
passiven Glasbruchsensoren nachzuweisen. Der
Prüfsignalgeber ist in die Frontplatte an der Oberseite des
Prüfgerätes eingearbeitet.
Die Prüfelektronik wird nur beim Betätigen der
Impulsgebertaste mit Strom versorgt. Beim Betätigen dieser
Taste werden ca. 8 hochfrequente Prüfimpulse pro Sekunde
erzeugt und an den Prüfsignalgeber weitergegeben. Bleibt die
Taste länger als 10 s gedrückt, erfolgt eine automatische
Abschaltung.
Solange die von der eingebauten 9 V - Batterie gelieferte
Spannung nicht unter 7,0 V sinkt, zeigt die grüne Leuchtdiode
die Prüfimpulse bei gedrückter Impulsgebertaste synchron an.
Ein gleichzeitiges Aufleuchten der roten Leuchtdiode (LED)
zeigt, daß die Batterie erschöpft ist und ausgetauscht werden
muß.
P/N 1078287 (ML) • REV B • ISS 11MAR19
