Installation and operating manual
(PVI-3.8/4.6-I-OUTD Rev.: 1.5)
VoutR 230 V
Vout AvgR 230 V
VoutX: measured instant phase / neutral grid voltage
Vout AvgX: average grid phase / neutral voltage calculated over the last 10 minutes of
inverter operation
VoutRS
Vout AvgR 230 V
VoutXX: measured instant concatenated voltage
IoutR
FoutR 50.01 Hz
Iout: measured instant grid current value
Fout: measured instant grid frequency value
Vin1: input instant voltage value measured at channel 1 input
Iin1 : input instant current value measured at channel 1 input
Vin2: input instant voltage value measured at channel 2 input
Iin2 : input instant current value measured at channel 2 input
Or:
In the case of configuration with one input connected and a second input connected in
parallel, this screen is shown instead of the 2 screens previously described.
VoutT
Vout AvgT 230 V
400 V VoutTR
Vout AvgT 230 V
5.6 A IoutS
FoutS
Vin1
I in1
Vin2
I in2
Vin
I in
230 V
400 V
5.5 A
50.01 Hz
0 V
0.0 A
0 V
0.0 A
0 V
0.0 A
Page 59 of 95
VoutS 230 V
Vout AvgS 230 V
VoutST 400 V
Vout AvgS 230 V
IoutS 5.8 A
FoutS 50.01 Hz
