Installation and operating manual
(PVI-3.8/4.6-I-OUTD Rev.: 1.5)
AUTO: Automatic light management. The light turns on every time a key is pressed,
and remains on for 30 seconds before gradually turning itself off.
- The INTENSITY key allows for the regulation of backlight intensity on a scale of 1
to 9
2) Contrast : Display light contrast
The scale of the display's light tones go from 0 to 9.
To select the number, press the UP and DOWN keys to scroll and then ENTER to
confirm your choice.
3) Buzzer: key tone setting
Selecting:
ON : key tones are on
OFF : key tones are off
5.5.6.3

Service

Only installation staff may access this function. A dedicated password, only supplied
by Power-One is necessary to gain access.
5.5.6.4

New password

This function is used to change the default password, 0000.
To enter your own personal code, the display keys must be used in the following way:
Use ENTER to scroll from one digit to another (from left to right)
Use ESC to return to the previous digit (from right to left)
Press ESC repeatedly to return to the previous menus, as described in chapter
5.5.3
Use DOWN to scroll through the numbers in descending order (from 9 to 0)
Use UP to scroll through the numbers in ascending order (from 0 to 9)
5.5.6.5

Currency

This function regards the energy output earnings.
Name: set the desired currency using the keys in the same way. The default currency is
the Euro.
Val/KWh: indicates the cost of 1 KWh expressed in the set currency. The default
setting is 0.50 Euros.
Name EUR
Val/KWh 00.50
Page 68 of 95
